Lincoln eCell

2-Position Robotic Cell, Enclosure, with Fanuc Arc Mate 100iBe



The eCell™ LR pre-engineered robotic welding cell is a fixed table, dual work zone unit designed for small to medium sized parts that can be welded. The layout is optimized to maximize the work envelope of the robot, and is ideal for flexible manufacturing systems allowing manufacturers
to install multiple robots in close proximity to save valuable floor space.

Unit Includes

  • Fanuc® ArcMate™ 100iBe 6-axis robot
  • Power Wave® 355M power source
  • Statiflex® 400-MS w/ MERV 14 Filter Welding Fume Extraction Base Unit
  • Power Feed® wire drive system (4-Roll)
  • 360 Amp Air-Cooled Welding Torch
  • Collision Guard/Torch Protection Software
  • (2) – 24 X 24 in. (0.6 X 0.6 m) Precision Machined Tooling Plates
  • Power Reamer Robotic Torch Cleaner
  • Work Zone: H x W x D = 41 x 30 x 39 in. (1.0 x 0.8 x 1.0 m)
  • Processes: CV-MIG, Pulsed-MIG, Flux-Cored, Metal-Cored
  • Input Power: 230 / 460 / 575 / 3PH / 60 (20KVA Max)
